Single Cartridge Filters
High Flow Drinking Water System provides 3-7 gpm of carbon filtered water. A single stage process removes sediment, treats for taste & odor improvement, and is also capable of eliminating high levels of chlorine.
Includes
➢ Perfect for seasonal and lake homes>
➢ Drinking water for boats and yachts
➢ Individual utility rooms and high flow stations
➢ All international voltages available
➢ Simple slide-out slide-in lamp replacement
➢ Housing wrench provided
➢ Customizing available
Optional cartridges available for lead, Guardia & cyst removal
Filter Specifications and Performance Data
➤ Unit comes with a 5 micron carbon block cartridge as standard equipment.
➤ Cartridge can be replaced as per client or user requirement.
| Part Number | Description | Micron (Nominal) | Chlorine Capacity* | Connection | Flow Rate | Case Weight | Shipping Dimension |
|---|---|---|---|---|---|---|---|
| RAYKS | Drinking Water System | 5 | 12,000 gal | ¼" or ½" NPT | 3–7 GPM | 23 LBS | 20 × 20 × 12" |
Other cartridges are available:
Specifications:
- Maximum Temperature: 125°F
- Maximum Pressure: 125 PSI
- Material of Construction: Reinforced Polypropylene
- Effective Cartridge Life: Recommended filter changes every 6 months to one year.
Replacement Cartridges
| Part Number | Description | Micron (Nominal) | Max GPM | Size | Case Quantity | Case Weight | Case Dimensions |
|---|---|---|---|---|---|---|---|
| CEP10E BLOCK CARBON |
Carbon Block Cartridge | 5 | 3–7* | 2.3/8" × 9.3/4" | 4 | 12.5# | 0.6 ft³ |
| P5 SERIES SPUN | Spun Poly Cartridge | 5 | 5 | 2.3/8" × 9.3/4" | 8 | 8# | 1.1 ft³ |
| OPTIONAL | Ultraviolet Lamp | – | 6 | – | 1 | – | – |
