Stainless Steel Vessels
Execution
➣ Stainless steel pressure vessels for filtration of water
➣ Materials SS 304-1.4301, SS 304L-1.4307 and SS 316L-1.4404
➣ Standard execution as well made-to-mesure upon request
➣ Standard design pressure : 6 bar
➣ Standard temperature: 60°C, on request up to 110°C
➣ Finish: pickling + passivation / 2-8 finish
➣ Conform PED-2014-68-EU.art.4.3
➣ On request optional with nozzle-plate
Internals
➣ Filterstars 0.2 or 0.5 mm
➣ 6 arms 2" or 8/16 arms 3" / DN100
➣ Mat. PP max. 60°C
➣ Mat. PPGV30S-max. 110°C
➣ Mat. PVDF - max. 135°C
➣ Mat. Stainless steel
Standard Dimensions
| Type | Ø Dia (mm) |
Cylindrical Height (mm) |
Volume (Liter) |
Total Height (mm) |
Weight (Kg) |
Inlet | Outlet | Air Vent |
Lateral Service Port |
Filling Port |
|---|---|---|---|---|---|---|---|---|---|---|
| F-50-S-INOX | 500 | 1500 | 320 L | 2000 | 46 kg | 2" | 2" | 5/4" | Ø100 | handhole |
| F-65-S-INOX | 650 | 1500 | 520 L | 2130 | 68 kg | 2" | 2" | 5/4" | Ø200 | handhole |
| F-80-S-INOX | 800 | 1500 | 900 L | 2250 | 110 kg | 3" | 3" | 5/4" | Ø200 | handhole |
| F-95-S-INOX | 950 | 1500 | 1300 L | 2300 | 180 kg | 3" | 3" | 5/4" | Ø200 | handhole |
| F-100-S-INOX | 1000 | 1500 | 1450 L | 2350 | 220 kg | 3" | 3" | 5/4" | Ø200 | Ø200 |
| F-110-S-INOX | 1100 | 1500 | 1750 L | 2350 | 245 kg | 3" | 3" | 5/4" | Ø300 | Ø200 |
| F-120-S-INOX | 1200 | 1500 | 2150 L | 2450 | 370 kg | 3" | 3" | 5/4" | Ø300 | Ø200 |
| F-140-S-INOX | 1400 | 1500 | 3000 L | 2600 | 420 kg | DN100 | DN100 | 5/4" | Ø400 | Ø200 |
| F-160-S-INOX | 1600 | 1500 | 4000 L | 2700 | 590 kg | DN100 | DN100 | 5/4" | Ø400 | Ø200 |
